Suspension - Control Arm and Ball Joint Assembly

Suspension Control Arm And Ball Joint Assembly | CB90054RD | Front ViewSuspension Control Arm And Ball Joint Assembly | CB90054RD | Back ViewSuspension Control Arm And Ball Joint Assembly | CB90054RD | Top ViewSuspension Control Arm And Ball Joint Assembly | CB90054RD | Additional ImagesSuspension Control Arm And Ball Joint Assembly | CB90054RD | 3/4 TopRugged chassis solutions for severe-duty vehicles | Dorman RD | CB90054RDSee the Dorman control arm and chassis quality difference | CB90054RD360 View | CB90054RD

CB90054RD

Suspension Control Arm And Ball Joint Assembly

Application Summary: Chevrolet Equinox 2017-10, GMC Terrain 2017-10

Where To Buy

Product Description

Need a no-compromise replacement control arm and ball joint assembly for a hardworking vehicle? Dorman RD chassis products are engineered specifically for severe-duty service applications. The RD on the packaging for this exclusive line of components stands for "rugged duty." That includes vehicles that must reliably perform in off-road work, heavy hauling, towing and other grueling conditions. The RD line is also ideal for emergency vehicles that require maximum dependability, like ambulances and off-road rescue trucks. RD ball joint housings are made of quenched and tempered steel rather than simple normalized steel and finished with an exclusive protective coating, resulting in a more durable and corrosion-resistant part. Necessary hardware is included and also features a corrosion-resistant coating. Where applicable, to streamline installation and help ensure that lubrication stays where it has to be, we pre-load every joint with premium grease in specially-designed grease boots with molded-in standoffs. With regular maintenance, RD steering and suspension parts are designed and manufactured to outperform and outlast anything else anything else in the automotive aftermarket. When vehicle downtime is not an option, this control arm and ball joint assembly is a great choice to replace damaged or failed original equipment on specified vehicles.

  • Upgraded direct replacement - this control arm and ball joint assembly is designed to match the fit of the OE design in specified severe-duty applications and is engineered for improved durability
  • No-compromise construction - specifically designed for vehicles used for off-road work, heavy hauling or towing and other tough commercial applications where readiness for duty is required
  • Durable construction - designed and manufactured to strict specifications for reliable performance and to offer the best choice for replacing a failed original control arm and ball joint on specified vehicles
  • Trustworthy quality - backed by a team of chassis product engineering and manufacturing experts in the United States and more than a century of automotive experience

Detailed Applications

Product Specifications

Adjustable: No
Attachments Included: Yes
Ball Joint Included: Yes
Ball Joint Installed: Yes
Ball Joint Mounting Type: Bolt In
Ball Joint Stud Length: 22.8 mm
Ball Joint Stud Type: Threaded
Ball Joint Thread Diameter: 12 mm
Bearing Material: Metal
Boot Color: Black
Boot Material: Polychloroprene
Bushing Color: Black
Bushing Inside Diameter: 16 mm; 13 mm; 13 mm
Bushing Length: 60 mm
Bushing Material: Steel
Bushings Included: Yes
Castle Nut Included: Yes
Cone Outside Diameter: 16.1 mm
Control Arm Color: Black
Control Arm Construction: Stamped
Control Arm Material: Steel
Control Arm Maximum Length: 332.8 mm
Control Arm Maximum Width: 340.3 mm
Control Arm Type: Stamped
Cotter Pin Included: Yes
Distance Between Bushings: 277.5 mm
Dust Boot Included: Yes
Dust Boot Material: Polychloroprene
End 1 Thread Diameter: 12 mm
End 1 Thread Pitch: 1.75 mm
End 1 Thread Size: 12 mm
Finish: Powder Coated
Grade Type: Standard Replacement
Grease Fitting Included: Yes
Greaseable: Yes
Length: 332.8 mm
Locking Nut Included: Yes
Mounting Hardware Included: Yes
Mounting Hole Diameter: 17 mm; 13 mm; 13 mm
Mounting Hole Quantity: 0
Package Contents: 1 Control Arm; 1 Ball Joint; 1 Castle Nut; 1 Cotter Pin; 1 Zerk Fitting
Pre-Greased: Yes
Reinforced: No
Steering Type: Manual
Suspension Grade Type: Standard Replacement
Thread Diameter: 12 mm
Thread Direction: Clockwise (Right)
Thread Pitch: 1.75 mm
Thread Size: 12 mm

OE Numbers

DIRECT OE CROSS
20945780 GENERAL MOTORS
25872722 GENERAL MOTORS
