Item Details

Steering - Tie Rod End

Steering Tie Rod End | TO96082 | 3/4 Top
Steering Tie Rod End | TO96082 | Top ViewSteering Tie Rod End | TO96082 | Left ViewSteering Tie Rod End | TO96082 | Right ViewSteering Tie Rod End | TO96082 | Additional ImagesSteering Tie Rod End | TO96082 | 3/4 TopDorman Premium XL Chassis Components Restore Factory Handling and Feel | TO96082360 View | TO96082

TO96082

Steering Tie Rod End

Application Summary: Fiat 500L 2020-14, Fiat 500X 2023-16, Jeep Compass 2024-17, Jeep Renegade 2025-15

Where To Buy

Product Description

This steering tie rod end directly replaces the original equipment tie rod on specific vehicle applications. It has undergone an industry-leading evaluation process to ensure smooth, safe operation.

  • Trustworthy replacement - this steering tie rod end assembly directly replaces the original equipment on specific vehicle applications
  • Durably designed - factory-sealed and precision-forged housing resists future corrosion
  • Reliably engineered - built to decrease wear rate and ensure overall strength
  • Trustworthy quality - backed by team of professional engineers and quality control specialists in the United States

Detailed Applications

Product Specifications

Adjustable: Yes
Ball Joint Included: Yes
Bearing Material: Polymer
Bolts Included: No
Center Mount Hole Quantity: 1
Center Mount Stud Quantity: 1
Color: Grey
Cone Outside Diameter: 19.9 mm
Dust Boot Included: Yes
Dust Boot Material: Polychloroprene
End 1 Attachment Type: Threaded
End 1 Gender: Female
End 1 Thread Diameter: 14 mm
End 1 Thread Direction: Counterclockwise (Left)
End 1 Thread Pitch: 1.5 mm
End 2 Attachment Type: Threaded
End 2 Gender: Male
End 2 Thread Diameter: 10 mm
End 2 Thread Direction: Counterclockwise (Left)
End 2 Thread Pitch: 1.5 mm
End 2 Threads Per Inch: 2
End 2 Type: Threaded
Finish: Coated
Grade Type: Standard Replacement
Grease Fitting Included: No
Greaseable: No
Head Drive Type: Smooth
Height: 72.8 mm
Housing Material: Steel
Length: 135 mm
Material: Steel
Mounting Hardware Included: Yes
Outside Diameter: 36.9 mm
Package Contents: 1 Outer Tie Rod; 1 Ball Joint; 1 Nut
Pre-Greased: Yes
Stud Type: Taper
Thread Pitch: 1.5 mm
Tie Rod End Thread Diameter: 14 mm
Tie Rod Material: Steel
Tube Diameter: 19.44 mm
Type: Straight
Weight: .99 lb
Width: 36.9 mm

OE Numbers

DIRECT OE CROSS
68210502AA CHRYSLER
68275052AA CHRYSLER
68351148AA CHRYSLER

Documents & Support

Technical Support Available

Phone: 1-866-933-2911
Email: techsupport@dormanproducts.com
