Item Details

Throttle Body

Electronic Throttle Body | 977-800 | Electronic Throttle Body | 977-800 | Additional ImagesElectronic Throttle Body | 977-800 | Front ViewElectronic Throttle Body | 977-800 | Back ViewElectronic Throttle Body | 977-800 | Top ViewElectronic Throttle Body | 977-800 | 3/4 TopDorman Electronic Throttle Bodies Featuring Exclusive Sensor Shield | 977-800Make each repair an improvement with Dorman throttle bodies | 977-800New and Improved Electronic Throttle Bodies from Dorman | 977-800360 View | 977-800

977-800

Electronic Throttle Body

Application Summary: Buick Lucerne 2011-06, Cadillac DTS 2011-06, Cadillac SRX 2009-07, Cadillac STS 2010-07, Cadillac XLR 2009-07

Where To Buy

Product Description

Original equipment throttle bodies often fail from moisture and oil intrusion and failed internal electronics. This Dorman OE FIX throttle body features a non-contact Hall effect sensor and proprietary Sensor Shield butterfly shaft seal to prevent future failures.

  • Upgraded design - this plug-and-play replacement throttle body features a contactless Hall effect sensor and proprietary Sensor Shield butterfly shaft seal to prevent future failures
  • New construction - 100% new aluminum, not remanufactured, for reliability and the convenience of no core charge
  • Rigorously tested - complies with Federal Motor Vehicle Safety Standards (FMVSS) and endurance-proven with over 1 million cycle tests
  • Trustworthy quality - vehicle try-on tested, and backed by a team of product experts in the United States and more than a century of automotive experience

Detailed Applications

Product Specifications

Adjustable: No
Airflow Rate: 130 CFM
Bore Diameter: 3.82 in.
Connector/Terminal Type: Blade
Electrical Connection Type: Male
FMVSS (Federal Motor Vehicle Safety Standards) Compliant: Yes
Fuel Injectors Included: No
Fuel System Grade: Gas
Fuel System Injection Type: Gas
Fuel System Type: Gas
Gasket Or Seal Included: No
Housing Color: Natural
Housing Material: Aluminum/PBT
Idle Air Control Motor Included: No
Inlet Diameter: 3.42 in.
Inlet Quantity: 1
Inlet Type: Flanged
Installation Hardware Included: No
Mounting Hardware Included: No
Outlet Diameter: 3.85 in.
Outlet Quantity: 1
Outlet Type: Non-Flanged
Package Contents: 1 Throttle Body Unit
Terminal Count: 6
Throttle Body Finish: Silver
Throttle Body Material: Aluminum
Throttle Body Mounted: No
Throttle Body Spacer Included: No
Throttle Body Type: Electronic
Throttle Position Sensor Included: Yes
Venturi Quantity: 0

OE Numbers

DIRECT OE CROSS
12580700 GENERAL MOTORS
12602800 GENERAL MOTORS
12615495 GENERAL MOTORS
