Steering - Knuckle Kit

Front Right Loaded Knuckle | 698-424 | Front Right Loaded Knuckle | 698-424 | Additional ImagesFront Right Loaded Knuckle | 698-424 | Front ViewFront Right Loaded Knuckle | 698-424 | Back ViewFront Right Loaded Knuckle | 698-424 | Top ViewFront Right Loaded Knuckle | 698-424 | 3/4 TopSave time, money and effort with Dorman loaded knuckles | 698-424Swapping a knuckle or replacing a bearing? Loaded knuckles are the DIYers best friend | 698-424The Fastest Way to Replace a Wheel Bearing with Dorman Products | 698-424Wheel Bearing and Hub Assembly for Select Toyota Sienna Models | 698-424360 View | 698-424

698-424

Front Right Loaded Knuckle

Application Summary: Toyota Sienna 2010-04

Where To Buy

Product Description

Fixing a worn wheel bearing would traditionally require a difficult procedure using a hydraulic press, or purchasing multiple components. This Dorman OE FIX loaded knuckle includes all critical components already assembled for a fast, simple, safe install. For repair shops, that makes it less likely that you will have a vehicle stuck in the service bay. For vehicle owners, that makes this formerly complex job requiring special equipment much easier.

  • Pre-pressed assembly - this complete loaded knuckle kit includes all necessary components ready for installation right out of the box
  • Saves hours - eliminates the possibility of extended time spent wrestling with individual corroded components
  • Simpler solution - no need for hydraulic press to perform complete bearing repair, making replacement faster and more predictable for both professionals and DIYers
  • Quality engineering - designed in the United States and backed by a century of automotive aftermarket experience

Detailed Applications

Product Specifications

Anti Lock Braking System: No
Anti-Lock Brake Sensor Included: No
Bolt Circle Diameter: 114.3 mm
Brake Pilot Diameter: 62 mm
Connector Quantity: 0
Connector Terminal Quantity: 0
Flange Bolt Hole Diameter: 114.3 mm
Flange Bolt Hole Quantity: 5
Flange Bolts Included: Yes
Flange Diameter: 76.3 mm
Flange Included: Yes
Flange Offset: 60.3 mm
Flange Shape: Circular
Hub Included: Yes
Hub Pilot Diameter: 34 mm
Package Contents: 1 Load Knuckle; 1 Axel Nut; Hardware
Spline Quantity: 30
Wheel Pilot Diameter: 60 mm
Wheel Stud Quantity: 5
Wheel Stud Size: M12 X 1.5
Wheel Studs Included: Yes

OE Numbers

NON-DIRECT OE CROSS
4321108010 TOYOTA
435020E030 TOYOTA
47781-08020 TOYOTA
90080-36193 TOYOTA
