Item Details

Intake Manifold

Engine Intake Manifold | 615-380 | Engine Intake Manifold | 615-380 | Additional ImagesEngine Intake Manifold | 615-380 | Additional ImagesEngine Intake Manifold | 615-380 | Additional ImagesEngine Intake Manifold | 615-380 | Additional ImagesEngine Intake Manifold | 615-380 | Additional ImagesEngine Intake Manifold | 615-380 | Back ViewEngine Intake Manifold | 615-380 | Top ViewEngine Intake Manifold | 615-380 | 3/4 TopEngine Intake Manifold | 615-380 | Front ViewHow to Install Dorman's 615-380 Intake Manifold | 615-380Why the Intake Manifold and Valve Cover on GM 1.4L Ecotec Engines Are Often Related Repairs | 615-380360 View | 615-380

615-380

Engine Intake Manifold

Application Summary: Buick Encore 2021-13, Chevrolet Cruze 2016-11, Chevrolet Cruze Limited 2016, Chevrolet Sonic 2020-12, Chevrolet Tracker 2015-13, Chevrolet Trax 2021-13

Where To Buy

Product Description

The original intake manifold often fails when the internal PCV valve becomes dislodged, leading to excessive oil consumption. This Dorman OE FIX intake manifold has been redesigned with a retaining pin for the valve to prevent future failure.

  • Improved design - this intake manifold has been redesigned to correct a common PCV valve failure in the original equipment design to reduce excessive oil consumption
  • Complete kit - this manifold includes a new throttle body gasket, port gaskets, fuel injector O-rings, MAP sensor O-ring and screws for a complete installation
  • Quality American construction - this intake manifold is engineered and manufactured in the United States of tough nylon polymer to resist cracking and warping
  • Related repair - this manifold often leads to failure in the valve cover's PCV diaphragm; a damaged valve cover will often need to be replaced at the same time as the manifold

Detailed Applications

Product Specifications

Air Conditioning Compressor Mount: No
Alternator Mount: No
Center Maximum Height: 9 in
Color: Black
EGR Ready: No
Front Maximum Height: 2.25 in
Gasket Or Seal Included: Yes
Grade Type: Standard Replacement
Heated Choke Port: No
High-Riser: No
Installation Instructions Included: Yes
Length: 18 in
Manifold Height (in): 8 in
Material: Nylon
Mounting Hole Diameter: 10.6 mm
Mounting Hole Quantity: 5
Package Contents: 1 Manifold; 4 Port Gaskets; 1 Throttle Body Gasket; 4 Fuel Injector O Rings; 1 MAP Sensor O Ring; 4 Self Tapping Screws
Port Outlet Dimensions: 37 mm x 19.5 mm
Port Quantity: 4
Rear Maximum Height: 4 in
Street Legal: Yes
Width: 9 in

OE Numbers

DIRECT OE CROSS
25200449 GENERAL MOTORS
28289977 GENERAL MOTORS
55577314 GENERAL MOTORS
55581014 GENERAL MOTORS
