HVAC Heater Hose Assembly

Engine Heater Hose Assembly | 626-369 | 3/4 Top
Engine Heater Hose Assembly | 626-369 | Engine Heater Hose Assembly | 626-369 | Additional ImagesEngine Heater Hose Assembly | 626-369 | Top ViewEngine Heater Hose Assembly | 626-369 | Left ViewEngine Heater Hose Assembly | 626-369 | Right ViewEngine Heater Hose Assembly | 626-369 | 3/4 TopCar leaking coolant from engine or HVAC? Check out Dorman’s replacements and OE FIX solutions | 626-369

626-369

Engine Heater Hose Assembly

Application Summary: Ford Expedition 2021-18, Lincoln Navigator 2021-18

Where To Buy

Product Description

Original equipment HVAC heater hose assemblies often fail due to cracks in the plastic Y-connector. This Dorman OE FIX replacement features an upgraded aluminum Y-connector to prevent similar failures in the future.

  • Upgraded material - this replacement engine heater hose assembly features aluminum Y-connectors for added durability
  • Application specific - designed to match the original fit and function of heater hoses on certain vehicle years, makes and models
  • Complete replacement - hoses come with necessary clamps for easy installation
  • Quality engineering - designed in the United States and backed by decades of automotive aftermarket experience

Detailed Applications

Product Specifications

Angle: 45 deg
Arm Length: 200.5
Axis 1 Length: 736.09 in
Axis 2 Length: 200.5 in
Axis 3 Length: 249.88 in
Bending Radius: 1 in
Branch Quantity: 3
Burst Pressure: 75 PSI
Centerline Length: 26 in
Clamps Included: Yes
Color: Black; Silver
Contains Spring: No
Coolant Hose Heat Shield Included: No
Coolant Hose Type: Branched
End 1 Attachment Type: Quick Connect
End 1 Inside Diameter: 1 in
End 1 Type: Quick Connect
End 2 Attachment Type: Quick Connect
End 2 Inside Diameter: 1 in
End 2 Type: Quick Connect
End 3 Attachment Type: Quick Connect
End 3 Inside Diameter: 1 in
End 4 Inside Diameter: 1 in
Grade Type: Standard Replacement
Heat Shield Included: No
Hose Attachment End 1: Quick Connect
Hose Attachment End 2: Quick Disconnect
Hose End (1) Outside Diameter (In): 1.25 in
Hose End (2) Outside Diameter (In): 1.25 in
Hose End (3) Outside Diameter (In): 1 in
Hose Material: Rubber
Hose Outside Diameter: 1
Hose Overall Length (In): 86.74
Hose Quantity: 3
Hose Shape: Molded Assembly
Inside Diameter: 16 mm
Length: 86.74 in
Material: Aluminum; Rubber; Mesh
Maximum Bend Angle: 45 deg
Maximum Operating Temperature (°F): 250
Maximum Working Pressure: 75 PSI
Modular: Branch
Modular Components Included: Branch
Molded: Yes
Mounting Bracket Included: No
Outside Diameter: 1 in
Package Contents: 1 HVAC Heater Hose Assembly
Protective Sleeve Attached: No
Protective Sleeve Included: No
Quick Connect Fitting Quantity: 3
Thermostatically Controlled: No
Working Pressure: 75

OE Numbers

DIRECT OE CROSS
JL1Z18472B FORD MOTOR COMPANY
